Mattress Packing Machine //HS-MP-50P

 Product Description

Automatic mattress packing machine HS-MP-50P

Product Description:
Automatic mattress packing machine HS-MP-50P, produced by our company is a function machine of the product line, lt is specially designed for the final package of the finished mattress in the end of the product line.
Automatic mattress packing machine HS-MP-50P, make use of plastic to pack finished mattress and then seal, so that protect the product and also make the product more elegant.

Technical characteristics:
1. The automatic level is extremely high , Under a manless working flow, the machine itself carried out all the operations from the feeding and processing to the delivering the mattress bodies.
2. Sited freely in the end of the product line, the machine will pack the finished products.
3. Highly packaging performace .Designed three work site, the machine will form a continuate package craftwork, in order to satisfy the requirement of high speed running.
4. Perfect seal of film provides more security in storage & delivery.
5. Accepts mixed product length, width and thickness, in any sequence / seal bars are self-adjusting for all mattress sizes.
6. CE-Conform / International standard components.
7. Automatically wraps mattresses or foundations up to 2 units in one minute.
8. Accepts mixed product length, width and thickness, in any sequence /seal bars are self-adjusting for all mattress sizes.
9. Accepts all kinds of finished mattresses and soft cushions made from sponge.
10. Available wrapper : PE, PVC, PU.
11. Unique water&wind- circulation system to chill heat-seal bars and provide perfect seal.
12. Compact design minimizes floor space.
13. Lateral reinforcements as film holder in the two sides to position extra film in different color or with logo mark.
14. Low and easy maintenance.
15. Easy to operate / short training period.








Mattress Width  800-2300mm
Mattress Height  80-500mm
Mattress Length 1600-2300mm
Packaging Speed 2 Pieces/minute
Air Consumption  Approx.60M3/H 0.8Mpa
Control PLC
Power Supply 380V/220V 50/60Hz 6KVA
Operative Temperature 0-+45℃
Machine weight 2300KG
